Automatic Yellow Sticky Trap Making Machine with Hot Melt Glue and PP Material for Pest Control
-
Vurgulamak
Hot Melt Glue Yellow Sticky Trap Making Machine
,PP Material Insect Glue Trap Production Line
,PLC Touch Screen Pest Control Trap Manufacturing Equipment
-
Makine adıBöcek tutkal rulo tuzakları yapma makinesi
-
Tutkal TürüSıcakta eriyen yapıştırıcı
-
Tuzak malzemesiPP
-
Makine tipiOtomatik
-
Mahine işleviböcek tutkal rulo tuzakları yapımı için
-
kaplama miktarıAyarlanabilir
-
Tutkal kaplama tipibir tarafı tutkal kaplama
-
Tutkal eritme cihazıSos, Salça, Reçel, Ketçap
-
Kontrol PaneliPLC'li dokunmatik ekran
-
Makine anahtar kelimeleriMavi Böcek Yapışkan Tuzak yapma makinesi
-
Menşe yeriÇin (Anakara)
-
Marka adıKSPACK
-
SertifikaCE ISO
-
Model numarasıHG-818
-
Min sipariş miktarı1
-
Fiyat18000
-
Ambalaj bilgileriişlenmiş tahta sandık
-
Teslim süresi20 Gün
-
Ödeme koşullarıT/T, D/P, D/A, Western Union
-
Yetenek temini30 set
Automatic Yellow Sticky Trap Making Machine with Hot Melt Glue and PP Material for Pest Control
Factory Direct Yellow Sticky Trap Making Machine
Complete insect glue trap production line for manufacturing pest control traps with automated continuous operation.
Production Process
The insect sticky board production process begins with roll material being straightened by the guide rail, then entering the gluing station for adhesive application. The material is conveyed to the winding shaft via conveyor belt for winding. When the winding length reaches the preset value, the material shaft automatically switches (cutting and feeding material). The equipment operates continuously without stopping, requiring operators only to collect finished products and replace paper cores.
Technical Specifications
| Parameter | Specification |
|---|---|
| Total Power | 21.75 kW |
| Maximum Unwinding Diameter | 800 mm |
| Maximum Cardboard Width | 300 mm |
| Paper Tube Inner Diameter | 76 mm |
| Effective Maximum Glue Coating Width | 290 mm |
| Glue Coating Uniformity | ±5% |
| Production Speed | 0-75 m/min |
| Rewinding Edge Neatness | ±2 mm |
| Coating Basis Weight Range | 20-80 g/m² |
| Air Compressor | 5-7 kgf/cm² |
| Power Supply | AC380V |
Equipment Features
- Continuous operation without stopping
- Automatic material switching and feeding
- Precise glue coating control
- High production efficiency
- Suitable for yellow and blue insect sticky traps
- Minimal operator intervention required
